Vendu uniquement avec les systèmes de mesure complets
Intensité jusqu’à 10 cd (fixe, vert, équatorial)
Batterie remplaçable et recyclable
Interface utilisateur intuitive intégrée
Fonctionnement du crépuscule à l’aube
Interrupteur externe en option
Paramètres intelligents de localisation pour une protection contre les erreurs de configuration
| Characteristic | Description / Value |
|---|---|
| Solar panel | High-efficiency cells with bypass and blocking diode function. Maximum power point tracking (MPPT) for optimal energy collection. |
| Battery | Tool-less replaceable and recyclable best-in-class battery pack with extreme temperature range. Battery status feedback of Good, Charge or Bad (Replace). |
| Light sources | High power LED. Colour-specific temperature corrected LED drivers provide consistent intensity under all operating conditions. |
| Intensity | 10 cd intensity, steady-on (see photometric plot on reverse). 18 cd peak intensity, flashing, 12.5% duty cycle (Red LEDs). |
| Flash patterns | 256+ |
| Construction | Premium grade UV resistant, polycarbonate/polysiloxane co-polymer body and lens material. Double O-ring sealing with waterproof vent. |
| Colours | Blue, Red, Yellow, Green and White. ICAO and SAE25050 (FAA) compliant chromaticity. |
| Ambient operation temperature (ALC) | -45 to 124 ºF (-43 to 51 ºC) ambient temperature. The A650 will function up to 190 ºF (88 ºC) internal and surface temperatures. |
| Storage temperature | -45 to 176 ºF (-43 to 80 ºC) |
| Colour indicator | Yes, FAA Eng. Brief 67 compliant. |
| Weight | 3.5 lb (1.58 kg) |
| Wind loading | 400 mph (180 m/s) |
| Automatic light control | When enabled, ALC will dynamically reduce brightness in response to unusually low amounts of sunlight to ensure continued operation. |
| Manufacturer | Carmanah Technologies Corp. |
