Ideal in all areas where people are, air purifiers can significantly improve the air quality. The Heylo air cleaner HL 800 is for use in apartments, offices, conference and training rooms, schools and authorities, practices and fitness centres.
The individual filter stages have the following functions:
1st stage
Pre-filter
A washable plastic filter is used as a pre-filter. The pre-filter filters coarse dust particles of more than 5 micrometers, such as house dust, scales, pollen. The filter can be washed out with water and can therefore be used several times. Heylo recommends replacing the pre-filter annually.
2nd + 3rd stage
Effective formaldehyde filter
The formaldehyde filter with activated carbon cleans the air of unwanted odours, gases and substances. It also cleans the air of harmful formaldehyde in a very short time. The substances are absorbed by the activated carbon and when the filter is saturated, it must be replaced. Heylo recommends this every 6 months.
In case of strong odour pollution, such as cigarette smoke, a more frequent change may also be advisable.
Highly efficient HEPA filter (suspended matter filter)
The HEPA filter filters airborne germs, smoke, and dust particles down to 1µm in size at a rate of 99% or more. In combination with the multifunctional filter, the HEPA filter can filter out microscopic particles with a diameter of more than 20 nanometres, including bacterial mould, dust, allergens, and some viruses. According to the World Health Organisation, the corona virus, avian flu virus, influenza virus and legionella bacteria are larger than 20 nanometres.
4th stage
Ionization
By applying strong electric fields, ionizers can electrically charge individual air particles and thus increase the ion concentration in the room air. The charged particles are more reactive and can thus destroy odour molecules and other pollutants. At the same time, differently charged particles attract each other and form larger lumps that sink to the ground faster and can be filtered out of the air more easily.
Key features
Product specifications
| Specifications | Units | HL 800 |
|---|---|---|
| Product code | 1960009 | |
| Ventilator-air flow without filters | m³/h | 1121 |
| Air flow with free M-filter F9 | m³/h | 800 |
| Air flow with free H-filter H14 | m³/h | 403 |
| Power consumption | kW | 0.09 |
| Power supply | V/Hz | 230/50-60 |
| Rated current | A | 0.4 |
| Protection class | IP | X0 |
| Sound level / 3m | dB(A) | 33-42 |
| Product size (l x w x h) | mm | 400 x 400 x 665 |
| Net weight | kg | 14 |
Suitable for
- Buildings and commercial spaces
- Camps and field hospitals
- Disinfection and pest control
- Leisure and recreation
- Military and aerospace
- Rental companies
